Video Mosaic（VDWALL）

Video Mosaic #VDWALL-VM

Price:US$ 180.⁰⁰

Model No:: VDWALL-LVPA600 VDWALL-LVP6082 VDWALL-LVP6081 VDWALL-LVP412 VDWALL-LVP404 VDWALL-LVP8601-H VDWALL-LVP8601-D VDWALL-LVP608-H VDWALL-LVP608-D VDWALL-SC-10

Quantity:


+Wishlist
Share:

MOQ : 1 piece Warranty :24 months Lead Time : 7 days

led display receiving card

led display receiving card

led display receiving card

led display receiving card

led display receiving card

linsn receiving card linsn control card

led display receiving cards sending card

receiving card sending card control card of led display

Model Number	LVP404/408/412	LVP8601-H	LVP8601-D	LVP608-H	LVP608-D	SC-10	LVP6081/6082
Brand	VDWALL
Input Output Interface Number	7	16	16	7		10	6
Input Interface	2×BNC, 1×DP( DisplayPort ), 1×VGA（RGBHV）, 1×DVI, 1×HDMI, 1×SDI / HD-SDI	CVBS x 4, VGA x 4, DVI x 4, SDI / HD-SDI / 3G-SDI x 4		1 x Video、2 x VGA、1 x DVI、1 x SDI、1 x DP1.2、1 x HDMI1.4		10 x DVI	2×Video 1×VGA（RGBHV） 1×HDMI（VESA/ CEA-861） 1×DVI（VESA/ CEA-861） 1×SDI（SDI/HD-SDI/3G-SDI）
Input Supports Resolution	1024×768@60Hz/75Hz, 1280×1024@60Hz/75Hz, 1366×768@60Hz, 1440×900@60Hz, 1600×1200@60Hz, 1920×1080p@50Hz/60Hz						1920×1080, 1600×1050, 1600×1200, 1600×900,1440×1050, 1440×900, 1366×768, 1360×768,1280×1024, 1280×960, 1280×800, 1280×768,1280×720, 1024×768, 800×600
Signal	TMDS
Standard	DVI 1.1
Output Interface Number	4/8/12	8	8	8	8	16	8
Output Interface	DVI					RJ45	DVI
Output Supports Resolutions	1920×1080, 1600×1050, 1600×1200, 1600×900,1440×1050, 1440×900, 1366×768, 1360×768,1280×1024, 1280×960, 1280×800, 1280×768,1280×720, 1024×768, 800×600
Splice Mode	Free splicing
Stitching Output Total Points	3648×2112	15360×8640		8000×2000		No	7680x4320
Power Supply	100-240VAC
Environment Temperature	0°C~45°C
Environment Humidity	15%-85%
Chassis Size	525×400×190mm	482.6×300×89mm	482.6×300×89mm	482.6×300×89mm	482.6×300×89mm	350×224×133.5mm	525×400×190mm
Weight	6.2kg	9kg	9kg	7.7kg	7.7kg	3.1kg	7.7kg
Certificate	CE,ROHS,FCC,ISO9001, TUV
