Hardware & Technical Specifications
Display
8 inches
Overall Size
Length 284 * width 140 * height 29mm
Processor
High-performance 32-bit 4-core ARM chip
Flash
8GB
Measurement Mode
Thermographic temperature measurement
Measuring Distance
0.3m - 0.8m (recommended 0.5m)
Communication Method
TTL
Temperature
Measurement Accuracy
± 0.2 oC ~ ± 0.5 oC
Operating Temperature
-20 ~ 65 oC for
Storage Temperature
-40 ~ 65 oC for
Power Supply
3-5V
Electric Current
2ma
Baud Rate
9600/115200
Default Automatic Output Frequency
14Hz
Wavelength Range
8 ~ 14µm
Temperature Output
Real-time parallel output
Temperature Correction
Manual and automatic calibration
Alarm Threshold
Adjustable
Wiegand Interface
Support Wiegand 26 Wiegand 34
Other Interface
232 TTL WIFI RJ45 USB
Style
Symmetrical design, can be hang horizontally and vertically
Camera
200w: USB connector, monocular wide dynamic, anti-glare
Aperture 2.8, focal length 1.6mm, field angle 130 °, TV distortion <-5%,
photosensitive area size 1 / 5-inch
Pixel: According to customer requirements, ≥ 2 million pixels.
Assembly angle: flat out
Image Sensor
6mm focal length, F2.4 aperture
Fill light
LED: white light, RGB camera fill light, a control interface in SDK
NIR: 850nm infrared LED light, IR camera fill light source, with control
interface in SDK
operating System
Android 5.1.1 or above
Input Power
DC 12V 2A
Backlight Recognition Iilluminance
< 6000Lux
Effective Recognition Distance
0.5m-4m
Working Environment
Indoor and outdoor (with rainproof frame), 10 ~ 90% (non-condensing)
Operating Temperature
-20 oC ~ + 55 oC
Card Reading Speed
0.2S
Matching
Matching
ID Card Reader
Support second-generation ID card recognition function, with control
interface in SDK
